This paper details a PDMS microfluidic system to perform dose response assays (what I’m hoping to achieve over this summer). They use serial dilutions to get separate trials spanning six orders of magnitude, showing an optimal dosage to kill HeLa cells. Their system is very efficient, using very shallow channels and balancing the fluid flux across all channels with a highly resistive design.
This week, I did a quick discoloration experiment based on Chris’s comment at lab meeting. He wondered if soaking the chips in water for a while would allow potential discoloration-causing contaminants to slowly leech out. I took 2 chips from wafer 622 and soaked them in ~ 300mL DIH20 overnight (with a couple of water…
Wafers 525 & 527 have a 1000 Å dry thermal oxide mask with all three films on the frontside sputtered. Both these wafers had a high density of pinholes. The pores are also irregular in shape and seem to have material “hanging” off the edges of the pores. Could this be a consequence of depositing…
In an attempt to push the cutoff higher, we annealed two wafers outside the susceptor at 1000 C (SC 066) and 1100 C (SC 067) with a ramp rate of 100 C/s. The 1100 C does give a cutoff slightly higher ~5 nm, but I’m not sure if this is within the variability in different…
Above video shows the disruption of the membrane from W404 after around 12 hours in the DMEM media (benchtop). The membrane was not treated with UV-Ozone and degraded pretty early as compared to that from W336 which broke at ~28 hrs. The membranes were loaded with 15um beads to check if they were intact and…
Hi All, just a quick post to up date you on what we are up to. 3 Things going on in the lab: Ryan continues to make his nano particles using chips, he is loading them with an anti-inflammatory agent (parthenolide) and testing them on macrophages in vitro. Hopefully more on that soon. Niecy just…
Hi everyone, in this update I’m going to go over some of the highlights from my experiments over the last month. After going through several trials that ultimately ended in failure, we moved over to testing long term performance of a 2.7% porosity nano-porous membrane (avg. pore diameter of 33.2 nm) by assessing it in…
